Accessing Endpoint Configuration from Groovy

Overview​

1Gateway exposes endpoint configuration values to Groovy scripts through the substitution mechanism.
This allows Groovy-based plugins to dynamically resolve endpoint URLs, credentials, and other configuration properties without hardcoding environment-specific values.

The substitution mechanism can be used to access endpoint configuration as well as other configuration variables available in 1Gateway.

Using substitution.substitute() with Endpoints​

Endpoint values are accessed by referencing the endpoint name and, optionally, a specific property.

Supported Substitution Keys​

substitution.substitute("endpoint:url")
substitution.substitute("endpoint:user")
substitution.substitute("endpoint:password")

Example​

Given an endpoint configuration named 1gateway-dev, there are multiple ways to access its values from Groovy.

configuration screenshot

Accessing the Endpoint Properties as a JSON Object​

You can retrieve the full endpoint configuration as a JSON string and parse it into a Groovy map:

def json = substitution.substitute("endpoint:1gateway-dev")
def endpoint = parser.asMap(json)

println endpoint.urlEndpoint
println endpoint.mandant

This approach is useful when you want to work with the full endpoint configuration in a structured way.

Accessing the Endpoint Properties Individually​

You can also retrieve individual endpoint properties directly using the property path syntax:

def url = substitution.substitute("endpoint:1gateway-dev/urlEndpoint")
def user = substitution.substitute("endpoint:1gateway-dev/user")
def password = substitution.substitute("endpoint:1gateway-dev/password")

println "Endpoint URL: ${url}"

Using Endpoint Credentials in REST Calls​

When making REST calls from Groovy, authentication can be configured using the endpoint name directly:

option.rest.useAuth("erp")

Credential Resolution Logic​

When you provide an endpoint name (for example via option.rest.useAuth("erp")), 1Gateway resolves credentials using the following logic:

  1. 1Gateway first checks whether a credentials profile exists with the same name.
  2. If no credentials profile is found, 1Gateway falls back to the credentials configured directly on the endpoint.

This allows endpoint-based authentication without explicitly retrieving or handling credentials in Groovy scripts.

Best Practices​

  • Use endpoint configuration instead of hardcoded URLs or credentials.
  • Prefer option.rest.useAuth(endpoint) for REST authentication.
  • Access endpoint configuration via substitution to ensure portability across environments.
